INSTALLATION
InstallingtheWeighScalebracket
Thebracketcanbemountedonaflatverticalsurface,oronaroundpost.
Tomountthebracketona
flatverticalsurface,for
exampleasquarepostor
board,usetheouterholes.
Tomountthebracketona
roundpost,usetheinner
holes.

Don'tmounttheWeighScalebracketontheweighingcrateorchute.
Installingtheloadbars
Toinstalltheloadbarsfollowthesesteps.
1. Bolttheplatformtotheloadbars.
2. Ensuretheplatformisplacedonaflatandlevelsurface.Makesureitisnot
touchinganyrailsorgates.
3. Eitherbolttheloadbarstotheconcretepadorlocatethemonstudssetinto
theconcrete.Thiswillpreventtheplatformfrommovingduringthe
weighingsession.
