Gap Diagnostic IIDTool Pro - Sub-Function Clear Faults; Access; App Access

82 83
IIDTool
GAP Diagnostic 2019-07-15 All Rights Reserved
User Manual : Version 33, Firmware V3.0
4.3.2 Sub-Function “ Clear Faults ”
II Access
TheIIDToolo󰀨erstwoclearingoptions:
Clear faults of a single ECU Or Clear faults on all ECUs
The “ Select ECU ” option
1-Perform the initial stages of general access
to functions (section 4.1.3)
2-Select “ Clear Faults ”
3-Select the “ Select ECU ” option
4-Navigate through ECUs available using
commands
5-Sélectionner le calculateur (ECU) désiré
avec la commande
The “ Clear All ” option
1-Perform the initial stages of general access
to functions (section 4.1.3)
2-Select “ Clear ”
3-Select the “ Clear All ” option
4-Wait until clearing is complete
App Access
See “ Read Faults ” sub-function , section 4.3.1
