Garage Smart Hard Top Lifter User Manual

ASSEMBLY
HARDTOP LIFTER INSTALLATION
2. Length Adjuster
1. There are four length adjusters (each with 34 holes), two
narrow (B) and two wide (A). Lay the narrow ones inside
the wide ones with the square holes at opposite ends.
(Fig 2.1a)
Both u-shaped bars open upward. These will later be
pinned in place. (Fig 2.1b)
2. Slide the width adjusters (C) through the square holes as
shown. Align holes with length adjuster openings as
shown. (Fig 2.2)
3. Assemble all six pieces together. (Fig 2.3)
Fig 2.3
Fig 2.1a
Fig 2.2
Fig 2.1b
8
