Garage Smart Hard Top Lifter User Manual

HARDTOP LIFTER INSTALLATION
1. SmartTrack Installation
1. Decide where to place your Hard Top Lifter by parking your
vehicle
in that location and assuring that there is enough
space around the vehicle to move and to open doors slightly.
2. Install SmartTracks so each
is across two ceiling joists. Place
them 15” apart on center above the vehicle’s intended
location. (Fig 1.1)
3. Mount myLifters on trac
ks 15” apart. They can be mounted
on the same rail (Fig 1.2a), or on opposite rails (Fig 1.2b),
depending on the direction of the ceiling joists relative to the
vehicle. Each lifter cable will fall along either side of the hard
top.
The carabiners will be hooked to the rails 15” from the
myLifters. This forms a 15-inch square on the ceiling.
4. Pair the Lifters to the App and create a “locked group.” Refer
to the MyL
ifter Manual for App instructions
Fig 1.1
Fig 1.2a
Fig 1.2b
CAUTION
Be sure to measure the 15-inch square when the
cable is mostly retracted.
SMARTTRACK
Front
Back
Front
Back
15”
15”
15”
15”
6
