17
GB
Problem Probable cause Remedy
Pump doesn’t start or No power. v Check fuses and electric
suddenly stops during connections.
operation
Dirt particles are jammed v Disconnect plug and clean
in the suction base. suction base (see
6. Maintenance).
Pump runs, but output Suction base is clogged. v Disconnect plug and clean
suddenly decreases suction base (see
6. Maintenance).
Only for the submersible
pump 7000:
Pump does not reach The suction base cover v Disconnect the plug from
residual water height of is missing in the suction base. the mains and install the
1 mm during flat suction suction base cover (see
6. Maintenance).
A
In the event of other faults please contact GARDENA Service.
Repairs should only be carried out by GARDENA service centres or dealers
authorised by GARDENA.
8. Technical Data
Submersible Pump Dirty Water Pump
Type 7000 (Art. 1780) 7500 (Art. 1795)
Rated power 250 W 340 W
Max. delivery capacity 7,000 l/h 7,500 l/h
Max. pressure 0.6 bar 0.6 bar
Max. delivery height 6 m 6 m
Max. submersion depth 7 m 7 m
Residual water level 1 mm 30 mm
Contaminated water with
particle size of max. 5 mm 25 mm
Power cable 10 m H05 RNF 10 m H05 RNF
Pump connection universal (G 1
¹⁄₄
"
M) / universal nipple
Min. water level for operation 35 mm 55 mm
Weight approx. (without cable) 4.3 kg 4.3 kg
Max. media temperature 35 °C 35 °C
Mains voltage /
mains frequency 230 V / 50 Hz 230 V / 50 Hz
Min./max. cut-in height 180 mm / 680 mm 200 mm / 690 mm
Min./max. cut-out height 70 mm / 140 mm 65 mm / 150 mm
Noise level L
WA
1)
48 dB(A) 55 dB(A)
1) Measuring method according to EN 60335-1
