Assembly
NOTE: Always refer to the full instruction detail and read all Safety
Instructions. Only use this guide as a checklist.
1. Attaching the Lower Handles (Fig B, C, & D)
Refer to page 16 for full instructions.
2. Attaching the Upper Handle Bar to the Lower Handles (Fig E/F)
Refer to page 17 for full instructions.
3. Assembly of the Hard Catcher /
4. Attaching the Hard Catcher (Fig H/K)
Refer to page 18 for full instructions.
Preparation
6. Adding and Checking the oil (Fig M/N/O)
(Always use good quality 4 stroke engine oil.
We recommend SAE 10W/30. Refer to page 20 for full instructions).
7. Fuelling (Fig Q) - Refer to page 21 for full instructions.
Operation
8. Starting the Engine (Fig R,S,T) - Refer to page 22 for full instructions.
Quick Start Guide Quick Start Guide
C.B. D.
TIGHTEN
LOOSEN
E. F.
TIGHTEN
LOOSEN
K.H. L.
LOWER
RAISE
N.
O.
HIGH
LOW
CORRECT
LEVEL
M.
TIGHTEN
LOOSEN
Q.
OPEN
T.S.R.
“I” = ON
“O” = OFF
X 3
5. Cutting Height
Adjustment (Fig L)
Refer to page 19
for full instructions.
- Use fresh unleaded fuel.
- DO NOT use ethanol based fuels
(Warranty will be void if the
engine becomes faulty due to
insucient oil and fuel level).
