Part Number 4533030 Rev 1 07/2017 13
Section 2 Installation
ELECTRICAL SPECIFICATIONS
Model Voltage Total kW Loading per Phase (kW) Amperage (A)
X-Y X-Z Y-Z Z-N 1 Phase X Y Z
GME36-I14C 120V / 208V Total 21.1kW
(Induction Range Top 4x
3.5kW, Oven 5.1kW)
10.4 5.3 5.3 0.1 Not
available
66.4 66.4 44.3
GME36-I20C 120V / 208V Total 26.8kW
(Induction Range Top 4x
5.0kW, Oven 5.1kW)
12.3 7.2 7.2 0.1 Not
available
82.2 82.2 60.3
Electrical Cable
• Power supply cable is not included. This equipment is
intended to be installed with fixed permanent wiring.
All electrical safety warnings must be complied. See
installation safety at the beginning of this chapter.
Three Phase Connection
• Unless otherwise noted, all ranges are shipped from the
factory for three phase connection.
Wiring Diagram
• Wiring diagram is shipped loose with the equipment.
Installation Instructions
UNCRATING
• Check the crate for possible damage sustained during
transit. Carefully remove the appliance from the crate
and again check for damage. Any damage to the
appliance must be reported to the carrier immediately.
• All packing material must be removed from the
appliance. The protective material covering the stainless
steel must be removed immediately, after the unit is
installed.
• All ranges are shipped from the factory with legs or
casters fitted unless specially ordered without.
• Do not remove permanently affixed labels, warnings
or data plates from the appliance, for this may void
approvals and create a safety hazard.
LEGS
• All ranges are shipped from the factory with legs
installed unless otherwise specified. Legs must be
adjusted to a minimum height of 6” [152mm] in order to
comply with NSF standards. See Installation Clearance.
• When the range is specified for dais or cove base
mounting, it is shipped less legs.
CASTERS
• The front casters on the unit are equipped with brakes
to limit the movement of the range without depending
on the electrical connection to limit appliance
movement.
• A restraint can be attached to the unit near the electric
connection. If the restraint is disconnected, be sure to
reconnect it after the range has been returned to its
originally installed position.
