Installation Section 2
Function Test
• Before Function Tests, read and understand
all installation safety instructions regarding
Personal Protection.
• Observe also ALL operation safety
requirements in section 3 Operation.
IMPORTANT: AIR MANAGEMENT SYSTEM
Incorporated in the Range are internal
cooling fans to manage airflow efficiently.
These cooling fans are turned on
automatically when:
• Any one of the induction hob is ON.
• Oven COOK/COOL switch is “I” (ON).
• Internal thermostat reads above set
temperature.
INDUCTION COOKTOP FUNCTION TEST
Testing procedure, for each induction hob:
1. Examine the cookware for induction cooking:
• Pans must be induction ready. See details in
section 3 Operation.
• Minimum pan size: Pan must have bottom
diameter larger than 12cm [5”]. Otherwise, the
pan will not be heated. This is a safety feature.
The sensors do not detect pan smaller than this
minimum size.
2. Put some water in an induction pan and place it in the
center of a cook-zone.
3. Turn the control knob to a ON position. The indicator
lamp illuminates and the water is heated.
ON Position
Any position
between
power levels
“1” to “12”.
Indicator
lamp. is on.
OFF Position
“0” on dial is
pointing to
the Indicator
lamp. The
lamp is off.
4. The Air System Cooling Fan
indicator lamp is ON.
5. Remove the pan away from the cook-zone.
NOTE: When power transmission to the pan bottom
stops, the indicator lamp blinks.
6. Place the pan back on the cook-zone. The heating
process resumes.
NOTE: The indicator lamp illuminates continuously
again when energy is being transferred to the pan.
7. Turn the control knob to the OFF position. The heating
process stops; the indicator lamp goes off.
OVEN FUNCTION TEST
Test the oven heat and fan functions using different COOK/
COOL, Dial, and door settings according to the table below.
Oven dial is in the OFF position when
o
F or
o
C is pointing to
the dial indicator lamp; the lamp is OFF.
COOK/
COOL
Switch
Oven Dial Door Oven
Heat
Elements
Oven
Fan
Air
System
Fan
O OFF / Set
Temp.
OPEN /
CLOSE
OFF OFF ON* /
OFF*
I OFF OPEN OFF OFF ON
I OFF CLOSE OFF ON ON
I Set Temp. CLOSE ON ON ON
I Set Temp. OPEN OFF OFF ON
II OFF / Set
Temp.
OPEN OFF ON ON* /
OFF*
II OFF / Set
Temp.
CLOSE OFF OFF ON* /
OFF*
* Air system fan is ON if internal thermostat reads above
set temperature; OFF if thermostat reads below set
temperature.
If the appliance does not function as expected, refer to
section 5 Troubleshooting.
