Garmin Apollo SL30 COMM User Manual

Specifications
Apollo SL30 Installation Manual
43
NAV RECEIVER PERFORMANCE
VOR
TSO/JTSO compliance............................. TSO-C40c (DO-196)/JTSO 2C40c
Applicable documents .............................. RTCA DO-196
Operational class ...................................... N/A
Accuracy category.................................... B {-46
o
C to + 55
o
C }
Frequency range ....................................... 108.00 to 117.95 MHz in 50 kHz increments
Frequency tolerance ................................. 0.0008%
Cross modulation products....................... At least 60 dB down
Receiver sensitivity .................................. 108 MHz –115 dBm typical
117 MHz –117 dBm typical
Course accuracy ....................................... RTCA DO-196 two sigma limit: 3
o
SL30 performance: less than 0.5
o
typical
Audio output............................................. With a 1 kHz tone 30% modulation at least 100 mW
output into 500 ohm loads
Ident/voice................................................ With 100 mV input, 30% modulation at 1020 Hz,
the ident/voice tone ratio shall not be less than15
dB
Audio response......................................... Less than 6 dB variation from 350 Hz to 2500 Hz
LOCALIZER
TSO compliance....................................... TSO-C36e (DO-195)/JTSO C36e
Applicable documents .............................. RTCA DO-195
Operational class ...................................... A {manual landing systems}
Accuracy category.................................... B {-46
o
C to + 55
o
C }
Frequency range ....................................... 108.00 to 111.95 MHz
Frequency tolerance ................................. 0.0008%
Cross modulation products....................... At least 60 dB down
Receiver sensitivity .................................. -115 dBm typical
Centering error ......................................... RTCA DO-195 two sigma limit: 6.6% of full scale
SL30 performance: less than 1.0% typical (1.5 mV)
Audio output............................................. With a 1 kHz tone 30% modulation at least 100 mW
output into 500 ohm loads
Ident/voice................................................ With 100 mV input, 30% modulation at 1020 Hz,
the ident/voice tone ratio shall not be less than15
dB
