Wire Label
Wire
Color
Wire
Gauge
Wire Function
SWITCH INPUT: CH9
TOGGLE 6 (OPTIONAL)
Orange 18 AWG
Latching switch input for CH 9-TOGGLE 6(10A) on this
wiring harness.
SWITCH INPUT: CH10
TOGGLE 7 (OPTIONAL)
Yellow 18 AWG
Latching switch input for CH 10-TOGGLE 7(10A) on this
wiring harness.
SWITCH INPUT: CH17 DIM
1 (OPTIONAL)
Black 18 AWG
Dimming switch input for CH 17-DIMMABLE 1(10A) on
the X2 wiring harness.
SWITCH INPUT: CH18 DIM
2 (OPTIONAL)
Brown 18 AWG
Dimming switch input for CH 18-DIMMABLE 2(10A) on
the X2 wiring harness.
SWITCH INPUT: CH19 DIM
3 (OPTIONAL)
Red 18 AWG
Dimming switch input for CH 19-DIMMABLE 3(10A) on
the X2 wiring harness.
SWITCH INPUT: CH25
MOMENTARY 1
(OPTIONAL)
Orange 18 AWG
Momentary switch input for CH 25-MOMENTARY 1
(10A) on the X2 wiring harness.
SWITCH INPUT: CH26
MOMENTARY 2
(OPTIONAL)
Yellow 18 AWG
Momentary switch input for CH 26-MOMENTARY 2
(10A) on the X2 wiring harness.
9
