Specifications
Trolling Motor
Weight (motor, mount,
and cables)
63in. white model:24kg (53lb.)
63in. black model:24.5kg (54lb.)
75in. white model: 24.5 kg (54lb.)
75in. black model: 25.4 kg (56lb.)
90in. white model: 25kg (55lb.)
Weight (stabilizer) 0.66kg (1.45lb.)
Operating temperature From -5° to 40°C (from 32° to 104°F)
Storage temperature From -40° to 85°C (-40° to 185°F)
Material
Mount and motor housing: aluminum
Shaft cap, display panel, and side panels: plastic
Motor shaft: fiberglass
Water rating
Shaft cap: IEC 60529 IPX5
1
Steering motor housing: IEC 60529 IPX7
2
Display panel housing: IEC 60529 IPX7
2
Propeller drive motor housing: IEC 60529 IPX8
3
Compass safe distance 61cm (2ft.)
Power cable length
63in. black model: 0.9m (3ft.)
63in. white model: 1.2m (4ft.)
75in. model: 1.2m (4ft.)
90in. model: 1.2m (4ft.)
Input voltage From 20 to 45Vdc
Input amperage 60A continuous
Breaker (not included)
42VDC or greater, suitable for 60A continuous
NOTE: You can protect the system by using a larger circuit breaker, not to exceed
90A, if you are operating under high temperatures or if you are sharing the circuit
with other devices. You should verify that your boat wiring meets marine wiring
standards using a larger breaker before changing it.
Main power usage at
36Vdc 60A
Off: 72mW
Full power: 2160W
Radio frequency
2.4GHz @ 17.4dBm Max
802.11 b/g/n @ 20 MHz
1
The part withstands projected water exposure from any direction (such as rain).
2
The part withstands incidental immersion in water up to 1m deep for up to 30min.
3
The part withstands continuous immersion in water up to 3m deep.
