GPS NAVIGATION
190-00692-00 Rev. B5-56
Garmin G1000 Pilot’s Guide for Piper PA32
5.12 NEAREST INTERSECTIONS (MFD)
Intersection
Identifier, Symbol,
Bearing, Distance
(within 200 nm of
current position)
Latitude and
Longitude
Reference VOR
Name,
Symbol, Frequency,
Bearing, Distance
Figure 5-52 Nearest Intersections Page
Map of
Surrounding Area
Selecting a nearest intersection:
1) Select the NRST Page Group.
2) Select the Nearest Intersections Page, the second page in the group.
3) Press the FMS Knob to activate the cursor.
4) Select the desired intersection. The information on the Nearest Intersection Page pertains to the selected
intersection.
To Next Page
