Garmin GHP 20 Marine Autopilot System with SmartPump User Manual

À
Shadow Drive
Á
Starboard line
Â
Return line
Ã
Port line
Ä
Shut-off valves
Å
Pump
Æ
Helm
Ç
Steering cylinder
Dual-Helm without Power Assist Layout
À
Return line
Á
Shadow Drive
Â
Starboard line
Ã
Port line
Ä
Shut-off valves
Å
Pump
Æ
Upper helm
Ç
Lower helm
È
Steering cylinder
Single-Helm with Power Assist Layout
NOTICE
The pump must be installed between the cylinder and the power-assist module to function correctly.
NOTE: Removal of the power assist-module may be necessary to gain access to the fittings, hoses, and bleed-tee fitting.
