190-02692-00 Rev. A
Garmin G100 Pilot’s Guide for the Piper PA-32 Saratoga 63
FLIGHT INSTRUMENTS
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICES INDEX
Flight Phase Annunciation* Automatic CDI Full-scale Deflection
Departure DPRT 0.3 nm
Terminal TERM 1.0 nm
Enroute ENR 2.0 nm
Oceanic OCN 4.0 nm
Approach
(Non-precision)
LNAV
1.0 nm decreasing to 350 feet depending on
variables (see previous figures)
Approach
(Non-precision with
advisory vertical
guidance)
LNAV + V
Approach
(LNAV/VNAV)
L/VNAV
1.0 nm decreasing to a specified course width,
then 0.3 nm, depending on variables (see previous
figures)
Approach
(LP)
LP
Approach
(LP with advisory
vertical guidance)
LP+V
Approach
(LPV)
LPV
Missed Approach MAPR 0.3 nm
* Flight phase annunciations are normally shown in magenta, but when cautionary conditions exist the
color changes to amber.
Table 2-1 Automatic GPS CDI Scaling
OBS MODE
NOTE: VNV is inhibited while automatic waypoint sequencing has been suspended.
Enabling Omni-bearing Selector (OBS) Mode suspends the automatic sequencing of waypoints in a GPS
flight plan (GPS must be the selected navigation source), but retains the current Active-to waypoint as the
navigation reference even after passing the waypoint. OBS is annunciated to the lower right of the aircraft
symbol when OBS Mode is selected.
While OBS is enabled, a course line is drawn through the Active-to waypoint on the moving map. If
desired, the course to/from the waypoint can now be adjusted. When OBS Mode is disabled, the GPS flight
plan returns to normal operation, with automatic sequencing of waypoints, following the course set in OBS
Mode. The flight plan on the moving map retains the modified course line.
