Garmin GPS 76 User Manual

37
Getting Started
37
Reference
Tracks
The Tracks Page displays the amount of Track Memory used, will allow you to
‘Save’ or ‘Clear’ the current Track Log, and displays a list of any Saved Tracks.
Save — When you select ‘Save’ you can choose how far back in the log
you wish to save. Select the appropriate choice, press ENTER to save the
selection.
Clear — The ‘Clear’ Button will allow you to clear the Track Log. If the Map
Page is becoming cluttered from all of your tracks, clearing the Track Log
will clean up the map.
Track Page Options
To access the Track Options, with the Tracks Page displayed, press the
MENU Key.
Delete Saved Track — If you have saved tracks, this option will allow you to
delete the saved track.
Delete All Tracks — This option will delete all saved tracks.
Setup Track Log — This selection displays the Track Log Setup menu. This
menu contains options for Track Recording, Record Method, and Interval.
• Record — ‘Off’, ‘Wrap When Full’ or ‘Stop When Full’. If ‘Wrap When
Full’ is selected, when track memory is full, the oldest track
point will be deleted and a new point added at the end.
• Record Method — Can be set to ‘Auto’, ‘Time’ or ‘Distance’.
• Interval — is used to select or enter an interval for the Record Method.
Main Menu
Tracks
Tracks Page Options
Main Menu — Tracks Page
190-00229-00.indd 07/25/01, 11:22 AM37

Garmin GPS 76 Specifications

General

Sport (fitness, running)	No
Marine (chartplotters, sounders)	Yes
Routes quantity	50
Tracks quantity	10
Number of waypoints	500
Form factor	Fixed
Product color	Gray
Interface	RS232, NMEA 0183, RTCM 104
Channels quantity	12 channels
GPS accuracy - position	15 m
GPS accuracy - velocity	0.05 m/s
Grayscale levels	4
Display resolution	180 x 240 pixels
Battery type	AA
Battery life (max)	16 h
Number of batteries supported	2
Sustainability certificates	RoHS
Operating temperature (T-T)	-15 - 70 °C

Weight and Dimensions

Depth	30 mm
Width	69 mm
Height	157 mm
Weight	218 g
