Bail Mounting the Device
NOTICE
If you are mounting the bracket on fiberglass with screws, it is recommended to use a countersink bit to drill a
clearance counterbore through only the top gel-coat layer. This will help to avoid cracking in the gel-coat layer
when the screws are tightened.
You can use a bail mount bracket (not included) to bail mount the device on a flat surface.
1 Using the bail-mount bracket as a template, mark the pilot holes.
2 Drill the pilot holes.
3 Using appropriate mounting screws (not included), secure the bail-mount bracket to the mounting surface.
4 Install the bail-mount knobs on the sides of the device.
5 Place the device in the bail-mount bracket and tighten the bail-mount knobs.
3
