Mercury
®
Engine Gauges
NOTE: This feature is available only when connected to the Mercury SmartCraft Connect gateway. The available
data varies based on the engine network and may include RPM, engine hours, coolant pressure, oil pressure, and
other data.
Select Vessel > Mercury to view the Mercury engine gauges.
Engine voltage or Mercury Steering Angle
2
Boat status
Boat speed
Fuel
Transmission gear
Engine speed
Trim tabs
Engine trim
TIP:
To view additional engine details, select Vessel > Mercury > Options > Engine Details.
2
The Mercury Steering Angle may appear on the display, depending on the engine model and configuration, and its location on the display may vary.
128 Gauges and Graphs
