Specifications
All Models
Specification Measurement
Temperature range From -15° to 55°C (from 5° to 131°F)
Material Polycarbonate plastic and die-cast aluminum
Water rating IEC 60529 IPX7
1
Input voltage From 10 to 32 Vdc
Fuse 10 A, 125 V fast-acting
NMEA 2000 LEN @ 9 Vdc 2
NMEA 2000 draw 75 mA max.
Clearance behind flush-mounted device 11.1 cm (4
3
/
8
in.)
Memory card 2 microSD card slots in the back of the device; 32 GB max. card size
Wireless frequency and transmit power 2.4 GHz @ 12.3 dBm maximum
8x10 Models
Specification Measurement
Dimensions (W × H × D) 25.9 × 20.5 × 7.5 cm (10.25 × 8.0625 × 2.95 in.)
Display size (W × H)
21.8 × 13.7 cm (8.6 × 5.4 in.)
10 in. diagonal
Weight 2.4 kg (5.2 lb.)
Compass-safe distance 45 cm (17.7 in.)
Max. power usage at 10 Vdc 40.1 W
Typical current draw at 12 Vdc 1.5 A
Max. current draw at 12 Vdc 6.0 A
1
The device withstands incidental exposure to water of up to 1 m for up to 30 min. For more information, go to www.garmin.com/waterrating.
17
