190-01553-00 GTR 200/200B Installation Manual
Rev. P Page 3-10
3.6.4.4 Softkey Setup Page
The Softkey Setup page (Figure 3-8) allows the installer to configure the operation of Softkey 1 (top) and
Softkey 2 (bottom), per the options listed in Table 3-6. Note that both softkeys cannot select the same
function (except Disabled).
Refer to
Section 3.6.4
to select the Softkey Setup Page. Use the LARGE Knob to scroll through the listed
functions, then use the SMALL Knob to adjust the setting of the function. After the setting has been
changed, turn the LARGE Knob to move the cursor to another function.
Figure 3-8 Softkey Setup Page
Table 3-6 Softkey Setup Page Selections
Selection Description
DISABLED Disables softkey
PILOT PTT* Radio transmits pilot MIC audio when key pressed
PILOT ISOLATION* Isolates pilot from copilot and music
MUSIC ON/OFF* Turns music input on/off
USER LIST Moves directly to user frequency list menu
TUNE EMERGENCY Sets active frequency to emergency frequency, 121.500
USR FREQ MEM CYCLE
Allows one of the softkeys to be used to cycle through stored user COM
frequencies
MEDIA CONTROLS */** Moves directly to media control menu
MEDIA PLAY/PAUSE */** Toggles between media control play and pause
TELEPHONE */** Moves directly to the telephone menu
*Indicates that function is not available when the intercom is set to off
**Indicates the function is only available on the GTR 200B model
