GARO GNM1D-RS485 User Manual

INFORMATION
GARO GNM1D-RS485 (GARO art nr 108044)
Warnings
Make sure the electrical power is off before start of
installation process.
All electrical installation must be performed by an
auhorized electrician.
MODBUS CONNECTION
Install the DLM meter in the mains cabinet you want to monitor.
Use shielded twisted pair cable between the DLM meter and the
wallbox.
Suitable cables:
CAT5 FTP, CAT5e FTP, CAT6 FTP, ELAKY-S, ELAQBY-S or similar.
3
EN
5 T
8 A-
6 B+
7 GND
A-
B+
PE
E-Meter
NOTE! JUMPER 5-8
DLM Meter GLB
Shielded Twisted Pair

GARO GNM1D-RS485 Specifications

General

Brand	GARO
Model	GNM1D-RS485
Category	Measuring Instruments
Language	English
