IC7 USER MANUAL
3
Overview
The Garw IC7 instrument cluster is a 7inch diagonal display unit designed
to display vehicle information real-time
The IC7 provides all the standard driver information expected along with
tell-tale lamps and warning symbols
All the data is collected via a wide range of inputs, configurable to
your vehicles requirements
Features
Up to 6 screens possible at one time all configured in vehicle with
individual settings for high/low warnings, units(KM/MPH,
Celsius/Fahrenheit etc.) ,colour scheme, rpm limit warning, shift indicator
Uploading of new graphics via USB
Wi-Fi connectivity for smartphone interface to change parameters read
battery and fuel level (additional features planned)
Customisable boot logo
Interfaces
7 x active low (warning lamps, trip reset)
6 x active high (tell-tale lamps for lights, turn signals)
4 x Analogue resistive inputs (for ntc temp sensors, fuel sensors)
1x Can bus
2 x Frequency inputs (1 hall, 1 hall or VR)
1 x Door switch input for booting IC7 when opening the door
2 x USB expansion for Wi-Fi, Camera, USB Drive
