GASSONIC OBSERVER-i
25
4.4.1. Error / Fault Output
Error/fault conditions are indicated in many ways:
• On the User Interface display
• Through the 4-20 mA analog output
• The Error/Fault relay will de-energize
• The HART digital information will show an error
• The Modbus digital information will show an error
• A fault event will be recorded every 30 seconds
Error / Fault Display AO Modbus Error relay User action
Gas
overrides
Low supply ERV- 0 mA* 0 mA De-energized
Restore proper
operating voltage
Yes
Acoustic
Error
ERAC
1 mA
**
0 mA De-energized
Check sound path from
piezo to microphone
Yes
Remote
alarm switch
stuck
EAST 0 mA* 0 mA De-energized Check switch wiring Yes
Remote relay
reset switch
stuck
ERST 0 mA* 0 mA De-energized Check switch wiring Yes
Magnetic
sensors
stuck
EMAG 0 mA* 0 mA De-energized Remove magnet Yes
Internal
voltage error
EINV 0 mA* 0 mA De-energized Return to factory No
Critical
memory error
ECRT 0 mA* 0 mA De-energized Return to factory No
User memory
error
EUSR 0 mA* 0 mA De-energized
Recycle power and
restore user defaults.
No
HART
memory error
EHRT 0 mA* 0 mA De-energized
Recycle power and
restore HART
information.
No
Event
memory error
EEVT 0 mA* 0 mA De-energized
Recycle power event
data maybe accurate.
No
Table 2: Error / Fault Indications
* See acoustic self-test sequence in Section 5.4. ** See HART output current in Table 1.
Low Supply
This fault occurs if the supply voltage at the Gassonic Observer-i drops below +12.5 VDC. When
the supply returns to normal, the Gassonic Observer-i will go back to start up.
Action - Ensure that the supply voltage is at least +14 VDC at the Gassonic Observer-i.
