Long Length Urethane g/m
XL ...................................1.9
L......................................3.0
H .....................................3.2
WH ..................................3.3
XH...................................9.1
T5 ...................................2.0
AT5 .................................2.7
T10 .................................3.6
WT10 ..............................3.9
AT10 ...............................4.2
T20 .................................5.9
AT20 ...............................7.3
HTD8 ..............................4.7
HTD14 ............................8.4
STD5 ..............................2.9
STD8 ..............................4.3
For a single V-belt, enter
1 rib/strand. When measuring a
PowerBand
®
(multiple) rib/strand
belt, enter the number of
ribs/strands per belt. Units are
grams/meter per rib or strand.
Super HC
®
g/m
3V ....................................72
5V ..................................200
8V ..................................510
3VX ..................................53
5VX ................................140
8VX ................................383
Super HC
®
PowerBand
®
g/m
3V ....................................96
5V ..................................241
8V ..................................579
3VX ..................................65
5VX ................................157
Predator
®
Singles g/m
5VP ................................217
8VP ................................528
AP ..................................114
BP ..................................174
CP..................................323
SPBP .............................208
SPCP .............................375
Predator
®
PowerBand g/m
3VP ..................................89
5VP ...............................217
8VP ................................528
BP ..................................212
CP..................................332
Hi Power
®
II g/m
A ......................................95
B ....................................168
C ....................................275
D ....................................553
E ....................................965
Hi Power
®
II PowerBand
®
g/m
A ....................................151
B ....................................200
C ....................................342
D ....................................663
Tri-Power
®
g/m
AX ....................................79
BX ..................................136
CX..................................216
Tri-Power
®
PowerBand
®
g/m
BX ..................................163
CX..................................281
