Gates 508C - Belt Mass Constants

11
Adjusted mass constants are for
standard stock belts only. Non-
standard belt constructions may
yield inaccurate results and may
require special adjusted mass
constants or special calibration
procedures. Units are grams/meter
per mm of width.
Poly Chain
®
GT
®
, GT
®
2
and GT
®
Carbon
™
g/m
5M (5mm) .......................3.0
8M (8mm) .......................4.7
14M (14mm) ...................7.9
19M (19mm) .................10.5
PowerGrip
®
GT
®
2 / GT3
and TruMotion
®
g/m
2M (2mm) .......................1.4
3M (3mm) .......................2.8
5M (5mm) .......................4.1
8M (8mm) GT2 ...............5.5
8M (8mm) GT3 ...............5.8
14M (14mm) GT2 ........... 9.6
14M (14mm) GT3 ........... 9.7
Twin Power
®
3M .............2.8
Twin Power
®
5M .............4.1
Twin Power
®
8M .............6.9
Twin Power
®
14M .........11.4
PowerGrip
®
HTD
®
and TruMotion
®
g/m
3M (3mm) .......................2.4
5M (5mm) .......................3.9
8M (8mm) .......................6.2
14M (14mm) ...................9.9
20M (20mm) .................12.8
Twin Power 3M...............2.7
Twin Power 5M...............4.6
Twin Power 8M...............7.2
Twin Power 14M...........12.3
PowerGrip
®
Timing g/m
and TruMotion
®
MXL (0.080”) ..................... 1.3
XL (0.200”) ........................ 2.4
L (0.375”) ........................... 3.2
H (0.500”) .......................... 3.9
XH (0.875”) ...................... 11.3
XXH (1.25”) ..................... 14.9
Twin Power XL .................. 1.9
Twin Power L..................... 3.2
Twin Power H .................... 4.6
Gates Mectrol
®
(Steel)
Long Length Urethane g/m
XL ...................................... 2.1
L......................................... 3.5
H ........................................ 3.9
H-HF .................................. 4.2
XH.................................... 10.5
T5 ...................................... 2.2
AT5 .................................... 3.2
ATL5 .................................. 3.6
T10 .................................... 4.3
T10-HF .............................. 4.6
AT10 .................................. 5.6
ATL10 ................................ 6.7
ATL10-HF .......................... 6.9
T20 .................................... 7.3
AT20 .................................. 9.9
ATL20 .............................. 10.8
HTD5 ................................. 4.1
HTD8 ................................. 5.9
HTD14 ............................. 10.7
HTDL14 ........................... 12.3
STD5 ................................. 3.9
STD8 ................................. 5.1
Belt Mass Constants
