Replacing Gateway 600YG2 Components
www.gateway.com
To add or replace memory modules:
1 Disconnect the AC adapter and modem and network cables and prepare
the notebook by following the instructions in “Preparing your work space”
on page 4.
2 Disconnect the notebook from the optional port replicator by following
the instructions in “Disconnecting from the port replicator” on page 7.
3 Turn the notebook over so the bottom is facing up.
4 Remove the main and optional secondary batteries by following the
instructions in “Removing the batteries” on page 8.
5 Loosen the captive screw that secures the memory cover. (The screw cannot
be removed.)
6 Lift the screw side of the cover upward, then slide the cover out.
