25
Replacing the hard drive in the hard drive kit
www.gateway.com
Replacing the hard drive in the
hard drive kit
Tools you need to complete this task:
Screws removed during this task:
To install a new hard drive into the kit:
1 Disconnect the AC adapter and modem and network cables and prepare
the notebook by following the instructions in “Preparing your work space”
on page 4.
2 Disconnect the notebook from the optional port replicator by following
the instructions in “Disconnecting from the port replicator” on page 7.
3 Turn the notebook over so the bottom is facing up.
4 Remove the main and optional secondary batteries by following the
instructions in “Removing the batteries” on page 8.
5 Remove the hard drive kit by following the instructions in “Replacing the
hard drive kit” on page 21.
Phillips #0 screwdriver
4 chrome 3 × 3.5 mm
(hard drive)
To Next Page
