Using Your Gateway Flat-panel Monitor www.gateway.com
6
9 Tighten the thumbscrew under the base with your fingers (or a flat
screwdriver) to secure the neck into place.
10 With the stand facing you, press the mounting bracket lever to the left and
hold it, then remove the bracket from the stand.
11 Attach the bracket to the LCD panel using the four screws you removed
previously.
Thumbscrew
Screws
Screws
8511808.book Page 6 Friday, November 17, 2006 9:56 AM
