Setting up the optional stand
www.gateway.com
5
5 Place the hinge cover over the hinge. The hinge cover came with your
optional stand.
6 Attach the hinge cover using the screw you removed from the original
neck hinge.
7 Remove the four small screws from the back of the LCD panel. Do not
discard the four screws.
8 Slide the adjustable stand’s neck onto the base.
Screw Screw
Screw
Screw
8511808.book Page 5 Friday, November 17, 2006 9:56 AM
