www.gateway.com
13
Installing the speaker bar
To install the speaker bar:
1 Tilt the screen back, then center the speaker bar below the screen. Make sure that the
speakers face forward.
2 Tighten the two thumbscrews on the back of the speaker bar.
3 Connect the speaker bar’s USB power cord to any available USB port on your computer.
4 Connect the speaker bar’s headphone (green) and microphone (pink) cables to your
computer’s headphone and microphone jacks.
5 If it is not already on, turn on your computer.
6 Turn on the speaker bar by rotating the power/volume knob clockwise.
Tip
When using the speaker bar with a DVI connection, we recommend that you
use the right-angle DVI cable so the speaker bar does not obstruct the cable.
8512088.book Page 13 Friday, January 12, 2007 3:31 PM
