Gavita Master EL2 User Manual

9
2. Product specifications
2.1. General product information
Product name Master Controller EL2
Product code 60.56.00.xx.xx
Producer Gavita Holland bv
2.2. Technical specifications
Controller dimensions (LxWxH) 127 x 22 x 75 mm
Weight 170 gram
Power supply
Adapter: 100V-240V AC 50/60hz -
5V DC (2000mA)
Maximum control voltage 11.5V
Maximum voltage/current alarm
contacts (NO/NC)
13,5V/50mA
Maximum cable length per port 100m (328ft)
Maximum number of ballasts per port 40
Total number of ballasts per controller 80
2.3. Environment
Warning! The product may not be exposed to moisture, condensing humidity,
contamination or dust.
Temperature range 0-35
O
C / 32 - 95
O
F
Operating humidity (non-condensing) <80%
2.4. Required tools
Task Tool
Mounting controller Screwdriver
Mounting controller Drill
Modify cable length (optional) RJ14 crimp tool
