GBC ProCut 20P - Table of Contents

Page ii
ProCut 20P – Installation and Operating Instructions
Introduction ................................................................ i
Features ................................................................ i
Benets ................................................................. i
Safety .................................................................... i
1. Safety
Cautions ................................................................ 1-2
General .................................................................. 1-2
Electrical ................................................................ 1-2
GBC Technical Service ......................................... 1-2
2. Warranty
Limited One Year Parts, 90 Days Labor Warranty;
USA, Mexico, and Canada .................................... 2-1
3. Specications
FCC Class A Notice .............................................. 3-2
Canada Class A Notice - Avis Canada, Classe A . 3-2
Modications ......................................................... 3-2
4. Installation
GBC Technical Service ......................................... 4-1
Prior to Installation ................................................. 4-1
Installation ............................................................. 4-1
Location ............................................................ 4-2
5. Feature Guide
Infrared Safety Walls ............................................. 5-1
Jogging Aid ............................................................ 5-1
Back Gauge ........................................................... 5-1
The Clamp & Cutting Blade ................................... 5-1
Cut Stick ................................................................ 5-1
Control Panel ......................................................... 5-2
A. LCD Display .................................................. 5-2
B. Keypad .......................................................... 5-2
C. Operation Buttons ........................................5-3
E. Blade Adjustment..........................................5-3
6. Operation
Powering Up the Machine ..................................... 6-1
Operating the Machine .......................................... 6-1
Manual Operation ............................................. 6-1
Programming the Machine .................................... 6-1
Entering a Program ........................................... 6-1
7. Operator Maintenance
Caring for the ProCut 20P ......................................7-1
Cleaning The Paper Cutter ................................7-1
Cut Stick Rotation and Replacement .................7-1
Blade Replacement ............................................7-1
8. Function Values
Changing Function Values .................................... 8-2
taBle oF contents
