GCI E84 Emulator Getting Started Manual
10
To remove a cycle, single click the desired cycle in the SELECTED CYCLES list, and click the Remove (left
arrow) button. The selected cycle will be removed from the SELECTED CYCLES list.
Clear List Button
This button clears the SELECTED CYCLES list.
Cycle Sorting Buttons
Two cycle sorting buttons positioned to the right of the SELECTED CYCLES list. The top button (displayed as
an upward pointing arrow) moves the selected cycle up one step in the SELECTED CYCLES list. The bottom
button (displayed as a downward pointing arrow) moves the selected cycle down one step in the
SELECTED CYCLES list.
Default Cycles Buttons
A set of Default Cycle buttons are provided that allow the user to quickly define one of four standard
Continuous Handoff sequences. These standard sequences include: Unload CS_0 - Load CS_0, Unload
CS_1 - Load CS_1, Load CS_0 - Load CS_1, and Load CS_1 - Load CS_0.
Test Setup Option Buttons
The same option buttons are provided as described above. These buttons allow the user to: run the
currently configured test suite, configure a new test suite, save the currently configured test suite, recall a
previously saved test, and return to the Main Menu.
