GE Interlogix NX-8 - Security NetworX System User Manual

Page 2
GENERAL DESCRIPTION
The NetworX NX-8 represents a new approach to security systems design. Drawing on our experience in the world
market as the largest exporter of USA manufactured controls, we have developed the most flexible, durable, and user-
friendly control ever seen in our industry. Featuring sophisticated software which allows up to 99 users to interface
with 48 zones, 8 partitions, and a host of integrated fire, access, verification, and input/output modules, all reported
with the most comprehensive and fast SIA and Contact ID formats. The NetworX design allows a fully loaded system
to be housed in one single metal enclosure, establishing for the first time, a logical solution and design response to
modular systems. Up to 32 modules can be added to expand the capabilities of the NX-8.
ORDERING INFORMATION
CADDX PART # DESCRIPTION
NX-8 KIT Includes NX-8 Control, NX-108E LED Keypad, & 16.5V 25VA Transformer
NX-8 NX-8 Control Only
NX-108E 8 Zone LED Keypad
NX-116E 16 Zone LED Keypad
NX-124E 24 Zone LED Keypad
NX-148E Alphanumeric LCD Keypad
NX-200 ** Zone Doubling Kit (Includes 100 3.74k and 100 6.98k resistors)
NX-216 16 Zone Expander Module
NX-320 ** Smart Power Supply and Buss Extender
NX-408E # 8 Zone Wireless Expansion Module (UL LISTED PART #60-904)
NX-416E # 16 Zone Wireless Expansion Module (UL LISTED PART #60-904)
NX-448E # 48 Zone Wireless Expansion Module (UL LISTED PART #60-904)
NX-507E Seven Relay Module
NX-508E Eight Output Module
NX-534E ** Two-Way Listen-In Module
NX-540E ** "Operator" Telephone Interface Module
NX-580E ** Cellemetry Interface
NX-870E ** Fire Supervision Module
NX-1192E 192 Zone LCD Keypad
NX-1208E 8 Zone LED Keypad
NX-1248E 48 Zone LCD Keypad
NX-1308E 8 Zone LED Door Design Keypad
NX-1316E 16 Zone LED Door Design Keypad
NX-1324E 24 Zone LED Door Design Keypad
NX-1448E 48 Zone Fixed Language Icon Keypad
** These products have not been tested and approved by Underwriters Laboratories, Inc.
# These wireless devices are only UL listed for residential applications.

GE Interlogix NX-8 - Security NetworX System Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320 power supply	12 VDC Regulated 2 AMPS + Control

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Operating Environment

operating temperature	32 to 120 degrees F
built-in siren driver	2-tone (Temporal and Yelp)
LED keypad current draw	130 mA max.

Weight and Dimensions

metal enclosure dimensions	11.25" Wide x 11.25" High x 3.50" Deep
shipping weight	9 lbs.
LED keypad dimensions	6.4" Wide x 4.0" High x 1.1" Deep
NX-148 LCD keypad dimensions	6.4" Wide x 5.3" High x 1.0" Deep
