GE Interlogix NX-8 - Security NetworX System User Manual

Page 7
PROGRAMMING THE NX-8 LED KEYPADS
This section describes how to program the address and partition of each keypad as well as the options that are
available. The address of the keypad is important because this is how the panel supervises the keypads.
The factory default for the Master code is [1]-[2]-[3]-[4] when using a 4-digit code or [1]-[2]-[3]-[4]-[5]-[6] for a 6-digit
code. The factory default for the "Go To Program" code is [9]-[7]-[1]-[3] for a 4-digit code or [9]-[7]-[1]-[3]-[0]-[0]fora
6-digit code.
[r] [9] [2] (Applies to LED keypad ONLY)
1) Enter [r][9][2][program code].
2) Enter the zone number (1 - 48) you want the keypad to start at.
3) Enter [r] to save and exit.
[r]-[9]-[3] Set keypad options
1) Enter [r]-[9]-[3][program code]- The "Service" LED will flash.
2) LEDs 1-8 can now be toggled on/off to enable/disable the following functions:
3) After enabling/disabling the desired functions press [r]
LED Keypad Feature Enabled
1
RESERVED. DO NOT PROGRAM THIS AT ALL!
2
Enable Silent Keypad option. Silences the entry/exit sounder & chime only.
3
Enable Ding Dong sound for Chime - If off, chime will be a single tone. (See location 40, page 22)
4
Enable Keypress Silence option
(silences the pulsing keypad sounder for 5 seconds when a key is pressed)
5
Enable Armed Status Suppression
(will not allow the keypad to display faulted or bypassed zones when the system is armed)
6
Enable Panic, Fire, Medical Beeptone
(will sound a short beep to verify that the keypress was accepted)
7
Suppresses the "Service" LED (NOTE: For UL installations, the Service LED shall not be suppressed
.)
(will not allow the "Service" LED to illuminate for any reason. If there is a system trouble, pressing [r]-[2
]
will still show the service menu.)
8
Enable multi-partition viewing
(enables temporary viewing of all partitions by pressing [r]-[1]-[partition number])
[r]-[9]-[4] Set Keypad Number and Partition
1) Enter [r]-[9]-[4]-[program code]- The "Service" LED and the "Instant" LED will flash.
2) Enter the keypad number (1-8)
3) Press [r]- The "Instant" LED will illuminate steady and the"Service" LED will remain flashing.
4) Enter the partition number for the keypad (The keypad will automatically exit this mode at this time)
[r]-[9]-[5] Set elapsed increments since last autotest
1) Enter [r]-[9]-[5]-[program code]-The "Service" LED will flash.
2) Enter [100's digit] -[10's digit]-[1's digit]-[#]
[r]-[9]-[6] Set system date
1) Enter [r]-[9]-[6]-[master code]. The "Service" LED will flash.
2) Enter [day of week (1=Sun)]-[month 10's digit]-[month 1's digit]-[day 10's digit]
[day 1's digit] -[year 10's digit]-[year 1's digit]
[r]-[9]-[7] Set system clock
1) Enter [r]-[9]-[7]-[master code]. The "Service" LED will flash.
2) Enter [hour 10's digit]-[hour 1's digit]-[minutes 10's digit]-[minutes 1's digit]

GE Interlogix NX-8 - Security NetworX System Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320 power supply	12 VDC Regulated 2 AMPS + Control

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Operating Environment

operating temperature	32 to 120 degrees F
built-in siren driver	2-tone (Temporal and Yelp)
LED keypad current draw	130 mA max.

Weight and Dimensions

metal enclosure dimensions	11.25" Wide x 11.25" High x 3.50" Deep
shipping weight	9 lbs.
LED keypad dimensions	6.4" Wide x 4.0" High x 1.1" Deep
NX-148 LCD keypad dimensions	6.4" Wide x 5.3" High x 1.0" Deep
