GE Interlogix NX-8 - Security NetworX System User Manual

Page 50
125 34 ZONE TYPE 8 CHARACTERISTIC SELECT 1-13-378
126 34 ZONE TYPE 9 ALARM EVENT CODE 7 _
127 34 ZONE TYPE 9 CHARACTERISTIC SELECT 6-1245-5678
128 34 ZONE TYPE 10 ALARM EVENT CODE 2 _
129 35 ZONE TYPE 10 CHARACTERISTIC SELECT 24-5-78
130 35 ZONE TYPE 11 ALARM EVENT CODE 3 _
131 35 ZONE TYPE 11 CHARACTERISTIC SELECT 3-0-0
132 35 ZONE TYPE 12 ALARM EVENT CODE 5 _
133 35 ZONE TYPE 12 CHARACTERISTIC SELECT 457-125-45678
134 35 ZONE TYPE 13 ALARM EVENT CODE 4 _
135 35 ZONE TYPE 13 CHARACTERISTIC SELECT 0-12458-5678
136 35 ZONE TYPE 14 ALARM EVENT CODE 7 _
137 35 ZONE TYPE 14 CHARACTERISTIC SELECT 5-12456-5678
138 35 ZONE TYPE 15 ALARM EVENT CODE 5 _
139 35 ZONE TYPE 15 CHARACTERISTIC SELECT 457-1256-5678
140 35 ZONE TYPE 16 ALARM EVENT CODE 4 _
141 35 ZONE TYPE 16 CHARACTERISTIC SELECT 0-12456-5678
142 36 ZONE TYPE 17 ALARM EVENT CODE 7 _
143 36 ZONE TYPE 17 CHARACTERISTIC SELECT 5-1245-25678
144 36 ZONE TYPE 18 ALARM EVENT CODE 5 _
145 36 ZONE TYPE 18 CHARACTERISTIC SELECT 457-125-25678
146 36 ZONE TYPE 19 ALARM EVENT CODE 4 _
147 36 ZONE TYPE 19 CHARACTERISTIC SELECT 0-1245-25678
148 36 ZONE TYPE 20 ALARM EVENT CODE 7 _
149 36 ZONE TYPE 20 CHARACTERISTIC SELECT 6-1245-25678
ZONE WORKSHEET
1 13 25 37
2 14 26 38
3 15 27 39
4 16 28 40
5 17 29 41
6 18 30 42
7 19 31 43
8 20 32 44
9 21 33 45
10 22 34 46
11 23 35 47
12 24 36 48

GE Interlogix NX-8 - Security NetworX System Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320 power supply	12 VDC Regulated 2 AMPS + Control

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Operating Environment

operating temperature	32 to 120 degrees F
built-in siren driver	2-tone (Temporal and Yelp)
LED keypad current draw	130 mA max.

Weight and Dimensions

metal enclosure dimensions	11.25" Wide x 11.25" High x 3.50" Deep
shipping weight	9 lbs.
LED keypad dimensions	6.4" Wide x 4.0" High x 1.1" Deep
NX-148 LCD keypad dimensions	6.4" Wide x 5.3" High x 1.0" Deep
