GE Interlogix NX-8 - Security NetworX System User Manual

Page 53
APPENDIX 3 EXPANDER NUMBERS FOR REPORTING EXPANDER TROUBLE
The tables below list the device numbers that will be reported for trouble conditions.
Device Device # reported
NX-8 Control Panel 0 See page 52 for possible report codes.
NX-534E Two Way Listen-In 64
NX-540E “Operator” 40 When product is available.
NX-580E Cellemetry Interface 76
NX-870E Fire Supervision 9 When product is available.
KEYPADS
KEYPAD PART 1 PART 2 PART 3 PART 4 PART 5 PART 6 PART 7 PART 8
1 192 193 194 195 196 197 198 199
2 200 201 202 203 204 205 206 207
3 208 209 210 211 212 213 214 215
4 216 217 218 219 220 221 222 223
5 224 225 226 227 228 229 230 231
6 232 233 234 235 236 237 238 239
7 240 241 242 243 244 245 246 247
8 248 249 250 251 252 253 254 255
HARDWIRE EXPANDER (NX-216) OUTPUT MODULE (NX-508 / NX-508E)
Starting zone number Expander # reported Address & Dip Switch Setting
Zone 9 (All switches off) 22
24
(Switch1&2on)
Zone 9 (Switch 1 on) 23
25
(Switch 3 on)
Zone 17 (Switch 2 on) 16
26
(Switch1&3on)
Zone 25 (Switch 1 & 2 on) 17
27
(Switch2&3on)
Zone 33 (Switch 3 on) 18
28
(Switch 1,2,&3 on)
Zone 41 (Switch 1 & 3 on) 19
29
(All switches off)
30
(Switch 1 on)
31
(Switch 2 on)
WIRELESS RECEIVER (NX-448 / NX-448E) REMOTE POWER SUPPLY (NX-320/NX-320E)
Switch Setting Expander # reported Address & Dip Switch Setting
All switches off 35
84
(All switches off)
Switch 1 on 36
85
(Switch 1 on)
Switch 2 on 37
86
(Switch 2 on)
Switches1&2on 38
87
(Switch1&2on)
Switch 3 on 39
88
(Switch 3 on)
Switches1&3on 32
89
(Switch1&3on)
Switches2&3on 33
90
(Switch2&3on)
Switch1,2&3on 34
91
(Switches 1, 2, & 3 on)

GE Interlogix NX-8 - Security NetworX System Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320 power supply	12 VDC Regulated 2 AMPS + Control

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Operating Environment

operating temperature	32 to 120 degrees F
built-in siren driver	2-tone (Temporal and Yelp)
LED keypad current draw	130 mA max.

Weight and Dimensions

metal enclosure dimensions	11.25" Wide x 11.25" High x 3.50" Deep
shipping weight	9 lbs.
LED keypad dimensions	6.4" Wide x 4.0" High x 1.1" Deep
NX-148 LCD keypad dimensions	6.4" Wide x 5.3" High x 1.0" Deep
