LOCAL TELEPHONE COMPANY INTERFACE INFORMATION
TELEPHONE CONNECTION REQUIREMENTS
Except for telephone company provided ringers, all connections to the telephone network shall be made through
standard plugs and standard telephone company provided jacks or equivalent in such a manner as to allow for
immediate disconnection of the terminal equipment. Standard jacks shall be so arranged that if the plug connected
thereto is withdrawn, no interference to the operation of the equipment at the customer’s premises which remains
connected to the telephone network, shall occur by reason of such withdrawal.
INCIDENCE OF HARM
Should terminal equipment or protective circuitry cause harm to the telephone network, the telephone company shall,
where practical, notify the customer that temporary discontinuance of service may be required. However, where prior
notice is not practical, the telephone company may temporarily discontinue service if such action is deemed
reasonable in the circumstances. In the case of such temporary discontinuance, the telephone company shall promptly
notify the customer who will be given the opportunity to correct the situation. The customer also has the right to bring a
complaint to the FCC if he feels the disconnection is not warranted.
CHANGES IN TELEPHONE COMPANY EQUIPMENT OR FACILITIES
The telephone company may make changes in its communications facilities, equipment, operations, or procedures
where such action is reasonably required and proper in its business. Should any such change render the customers
terminal equipment incompatible with the telephone company facilities, the customer shall be given adequate notice to
make modifications to maintain uninterrupted service.
GENERAL
The FCC prohibits customer provided terminal equipment be connected to party lines.
IMPORTANCE OF THE RINGER EQUIVALENCE NUMBER
The Ringer Equivalence Number (REN) of this device is 0.1B. This number is a representation of the electrical load
that it applies to your telephone line.
MALFUNCTION OF THE EQUIPMENT
In the event that the device should fail to operate properly, the customer shall disconnect the equipment from the
telephone line to determine if it is the customers equipment that is not functioning properly. If the problem is with the
device, the customer shall discontinue use until it is repaired.
EQUIPMENT INFORMATION
MANUFACTURER OF CONNECTING EQUIPMENT: CADDX CONTROLS, INC.
FCC REGISTRATION NUMBER: GCQUSA-31771-AL-T, RINGER EQUIVALENCE: 0.1 B

GE Interlogix NX-8 - Security NetworX System Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320 power supply	12 VDC Regulated 2 AMPS + Control

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Operating Environment

operating temperature	32 to 120 degrees F
built-in siren driver	2-tone (Temporal and Yelp)
LED keypad current draw	130 mA max.

Weight and Dimensions

metal enclosure dimensions	11.25" Wide x 11.25" High x 3.50" Deep
shipping weight	9 lbs.
LED keypad dimensions	6.4" Wide x 4.0" High x 1.1" Deep
NX-148 LCD keypad dimensions	6.4" Wide x 5.3" High x 1.0" Deep
