GE Interlogix NX-8 - Security NetworX System User Manual

Page 25
L LOCATION 51 - AUTOTEST CONTROL (4 segments, numerical data)
Segment 1: Program a "1" if the interval is to be in hours; Program a "0" if in days. Add a A2" to suppress the daily
test or a A3" to suppress the hourly test if any report has been sent.
Segment 2: Program the Autotest interval from 1-255 hours/days.
Segment 3: Program the Autotest report hour in 24 hour format (if the interval is in hours, this segment is ignored).
Segment 4: Program the Autotest report time, number of minutes after the hour.
LOCATION 52 - OPENING TIME (2 segments, numerical data)
Location 52 contains the time in 24 hour format the NX-8 enables codes designated as arm only after closing. This
time is only valid on those days programmed in location 54. Note: Opening time must be earlier than closing time for
Auto Arm, Aux. Outputs, or Code Authorization to function properly.
Segment 1: Program the hour of the opening time.
Segment 2: Program the minutes after the hour of the opening time.
LOCATION 53 - CLOSING TIME/AUTOMATIC ARMING TIME (2 segments, numerical data )
Location 53 contains the time in 24 hour format the NX-8 disables the disarm capability for codes designated as arm
only after closing. This is also the time the Automatic Arming sequence will begin (if enabled in location 55). Note:
Opening time must be earlier than closing time for Auto Arm, Aux. Outputs, or Code Authorization to function properly.
Segment 1: Program the hour of the closing / auto arm time.
Segment 2: Program the minutes after the hour of the closing / auto arm time.
LOCATION 54 - DAYS OF THE WEEK EACH PARTITION IS OPEN (8 Segments, feature selection data)
Location 54 selects which days of the week each partition is open. On these days, Aarm only after close window@
codes will be able to arm and disarm during open window. NOTE: If any partition is not programmed to be opened
and is programmed to Auto-Arm (Location 55), the NX-8 will try to arm every45 minutes for the duration of the
closed period. On days not selected here, Aarm only after close window@ codes will not disarm. Segment 1 is for
partition 1, and segment 8 is for partition 8. (See locations 52 and 53 for the opening and closing times for the
open days.)
Segment 1-8: 1 - Open on Sunday.
2 - Open on Monday.
3 - Open on Tuesday.
4 - Open on Wednesday.
5 - Open on Thursday.
6 - Open on Friday.
7 - Open on Saturday.
8 - Reserved.
LOCATION 55 - DAYS OF THE WEEK FOR AUTO ARMING IN PARTITIONS 1 THRU 8 (8 Segments, feature
selection data)
Location 55 selects which days each partition will auto arm. Segment 1 is for partition 1, and segment 8 is for partition
8. If a zone is faulted when the panel tries to auto arm, the zone will be bypassed.
Segments 1-8: 1 - Auto Arming on Sunday.
2 - Auto Arming on Monday.
3 - Auto Arming on Tuesday.
4 - Auto Arming on Wednesday.
5 - Auto Arming on Thursday.
6 - Auto Arming on Friday.
7 - Auto Arming on Saturday.
8 - Reserved.

GE Interlogix NX-8 - Security NetworX System Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320 power supply	12 VDC Regulated 2 AMPS + Control

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Operating Environment

operating temperature	32 to 120 degrees F
built-in siren driver	2-tone (Temporal and Yelp)
LED keypad current draw	130 mA max.

Weight and Dimensions

metal enclosure dimensions	11.25" Wide x 11.25" High x 3.50" Deep
shipping weight	9 lbs.
LED keypad dimensions	6.4" Wide x 4.0" High x 1.1" Deep
NX-148 LCD keypad dimensions	6.4" Wide x 5.3" High x 1.0" Deep
