GE Interlogix NX-8 - Security NetworX System User Manual

Page 24
AUXILIARY OUTPUT EVENT SELECTION
DATA EVENT DATA EVENT
0 /
Burglary Alarm
26
Fire Trouble
1 /
Fire Alarm
27
Chime
2 /
24 Hour Alarm
28 /
Expander Trouble
3 /
Trouble Alarm
29
Dynamic Battery Test Time
4 /
Tamper Alarm
30
Open Period
5
Yelping Siren (Burglary)
31
Closed Period
6
Temporal Siren (Fire)
32
Listen-In
7
Any Siren
33
Line Seizure
8
Any Bypass
34
Ground Start
9
AC Fail
35
Fail To Communicate
10
Low Battery
36
Telephone Line Fault
11 /
Duress
37
Program Mode
12 /
Aux 1 Keypad Zone
38
Download In Process
13 /
Aux 2 Keypad Zone
39
Ground Fault
14 /
Panic Keypad Zone
40
Short Circuit (Over-current)
15
Keypad Tamper
41
Box Tamper
16 /
Autotest
42
Siren Tamper
17
Alarm Memory
43
Any Open
18
Entry
44
Any Short
19
Exit
45
Any Fault (Open/ Short on Non-Fire Zone)
20
Entry or Exit
46 /
Any Alarm
21
Armed State
47
Beeping Keypad
22
Disarmed State
48 /
Code Entry (See note below)
23
Ready
49 ˜/
Key FOB Function 1
24
Not Ready
50 ˜/
Key FOB Function 2
25
Fire
˜ Events 49 & 50 require NX-408, NX-416, or NX-448 wireless receivers to operate.
/ If set to follow condition, these events will be 1 second.
Notes : When Event 48 is programmed, it is possible to program a user code's authorization to select which output(s)
a particular code will activate. When LED 8 is on for an authorization, then LEDs 1- 4 correspond to that code
activating outputs 1 - 4 respectively. (See programming the LED keypads on page 8.)

GE Interlogix NX-8 - Security NetworX System Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320 power supply	12 VDC Regulated 2 AMPS + Control

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Operating Environment

operating temperature	32 to 120 degrees F
built-in siren driver	2-tone (Temporal and Yelp)
LED keypad current draw	130 mA max.

Weight and Dimensions

metal enclosure dimensions	11.25" Wide x 11.25" High x 3.50" Deep
shipping weight	9 lbs.
LED keypad dimensions	6.4" Wide x 4.0" High x 1.1" Deep
NX-148 LCD keypad dimensions	6.4" Wide x 5.3" High x 1.0" Deep
