SETPOINTS MODE
5-8
Analog In Alarm 12.00. Min Curr Scale Value to Max Curr Scale Value
Analog In Alarm Delay 1 Sec. 1 to 255 sec 1 sec
Analog In Alarm Relay Aux1. (Aux2 for 575) Aux1, Aux2, Aux1&2 (575: None, Aux1, Aux2, Aux1&2)
6. Analog Output setpoints.
Analog Output Parameter Phase A Current. Phase A Current, Phase B Current, Phase C Current,
Ground Current, Phase A-X Voltage, Phase B-X Voltage,
Phase C-X Voltage, Feeder Frequency, and External
Analog Select
Analog Output Range: 4-20 mA. 0-1mA or 4-20mA
7. Communication setpoints.
Relay Address 1. 1 to 254 1
Baud Rate 2400 BAUD. 1200, 2400, 4800, and 9600 Baud
8. Calibration Mode setpoints.
Exercise Relay Trip. Trip, Aux1, Aux2, Aux3, and All (565)
Trip, Aux1, Aux2, Aux3, Aux4, Block Tap Changer, and
All (575)
(Status of Switch Inputs)
LCD Display Contrast 5. 0 to 10 1
9. Voltage setpoints.
VT Connection Wye. Wye, Open Delta, Delta/Wye and None
VT Nominal Sec Volts 120 Volts. 48 to 240 Volts
VT Primary Volts 1.2 kV. 0.1 to 69 kV 0.01 kV
Zero Volts Detect Disabled. Enabled/Disabled
Undervolt Trip Disabled. Enabled/Disabled
Undervolt Trip Level 80% VT 50 to 100% 1%
Undervolt Trip Delay 1.0 Sec. 0.1 to 25.5 sec 0.1 sec
Undervolt Trip Relay Trip & Aux1. Trip, Aux1, Aux2, Trip&Aux1, Trip&Aux2, Aux1&2, and
Trip&Aux1&2 (575: Trip, Trip&Aux1, Aux2)
Undervolt Alarm Disabled. Enabled/Disabled
Undervolt Alarm Level 85% VT 50 to 100% 1%
Undervolt Alarm Delay 1.0 Sec. 0.1 to 25.5 sec 0.1 sec
Undervolt Alarm Relay Aux2. Aux1, Aux2, and Aux1&2 (575: None, Aux1, Aux2,
Aux1&2)
Overvolt Trip Disabled. Enabled/Disabled
Overvolt Trip Level 120% VT 101 to 125% 1%
Overvolt Trip Delay 1.0 Sec. 0.1 to 25.5 sec 0.1 sec
Overvolt Trip Relay Trip. (Trip&Aux1 for 575) Trip, Aux1, Aux2, Trip&Aux1, Trip&Aux2, Aux1&2, and
Trip&Aux1&2 (575: Trip, Trip&Aux1, Aux2)
Overvolt Alarm Disabled. Enabled/Disabled
Overvolt Alarm Level 115% VT 101 to 125% 1%
Overvolt Alarm Delay 1.0 Sec. 0.1 to 25.5 sec 0.1 sec
Overvolt Alarm Relay Aux1. (Aux2 for 575) Aux1, Aux2, Aux1&2 (575: None, Aux1, Aux2, Aux1&2)
10. Demand Metering setpoints.
Amps Demand Enabled. Enabled/Disabled
Amps Demand Time Period 5 Min. 5 to 120 Min 1 Min
Amps Demand Alarm Disabled. Enabled/Disabled
Amp Demand Alarm Level 100 A. 10 to 5000 A 5 A
Setpoint Name Factory Setpoint Range Step
