GE Security FireShield FS1004 User Manual

Programming templates
FireShield Technical Reference Manual B.3
System event reporting setup
Event Where to report the event 4/2 event code
Panel test  None  CS 1  CS 2  CS 1 & 2 DF
Panel abnormal test  None  CS 1  CS 2  CS 1 & 2 6F
Walk test  None  CS 1  CS 2  CS 1 & 2 AF
Drill  None  CS 1  CS 2  CS 1 & 2 AD
Reset  None  CS 1  CS 2  CS 1 & 2 AB
Program mode  None  CS 1  CS 2  CS 1 & 2 C1
DACT Disabled  None  CS 1  CS 2  CS 1 & 2 AE
Panel silence  None  CS 1  CS 2  CS 1 & 2 CA
Signal silence  None  CS 1  CS 2  CS 1 & 2 AC
Ground fault  None  CS 1  CS 2  CS 1 & 2 66
Low battery  None  CS 1  CS 2  CS 1 & 2 6C
Missing battery  None  CS 1  CS 2  CS 1 & 2 6C
Internal comm trouble  None  CS 1  CS 2  CS 1 & 2 AA
AC fail  None  CS 1  CS 2  CS 1 & 2 69
Charger trouble  None  CS 1  CS 2  CS 1 & 2 6B
Transformer 2 trouble  None  CS 1  CS 2  CS 1 & 2 6A
Aux power trouble  None  CS 1  CS 2  CS 1 & 2 65
Peripheral trouble  None  CS 1  CS 2  CS 1 & 2 6D
DACT line 1 trouble  None  CS 1  CS 2  CS 1 & 2 68
DACT line 2 trouble  None  CS 1  CS 2  CS 1 & 2 6E
DACT delivery trouble  None  CS 1  CS 2  CS 1 & 2 67
System trouble restoral (4/2 code) (0 – F) D
Zone settings - IDC 1
Note: For IDCs, program only those events that apply to the IDC zone type you specified on the “Panel programming worksheet.”
Event Where to report the event 4/2 event code
Alarm activation  None  CS 1  CS 2  CS 1 & 2 11
Waterflow activation  None  CS 1  CS 2  CS 1 & 2 21
Trouble activation  None  CS 1  CS 2  CS 1 & 2 71
Supervisory activation  None  CS 1  CS 2  CS 1 & 2 31
Monitor activation  None  CS 1  CS 2  CS 1 & 2 51
Zone settings - IDC 2
Event Where to report the event 4/2 event code
Alarm activation  None  CS 1  CS 2  CS 1 & 2 12
Waterflow activation  None  CS 1  CS 2  CS 1 & 2 22
Trouble activation  None  CS 1  CS 2  CS 1 & 2 72
Supervisory activation  None  CS 1  CS 2  CS 1 & 2 32
Monitor activation  None  CS 1  CS 2  CS 1 & 2 52
Zone settings - IDC 3
Event Where to report the event 4/2 event code
Alarm activation  None  CS 1  CS 2  CS 1 & 2 13
Waterflow activation  None  CS 1  CS 2  CS 1 & 2 23
Trouble activation  None  CS 1  CS 2  CS 1 & 2 73
Supervisory activation  None  CS 1  CS 2  CS 1 & 2 33
Monitor activation  None  CS 1  CS 2  CS 1 & 2 53
Note: Default settings are shown in boldface type.
