CHAPTER 1: INTRODUCTION SPECIFICATIONS
345 TRANSFORMER PROTECTION SYSTEM – QUICKSTART GUIDE 13
EAC
The EAC Technical Regulations (TR) for Machines and Equipment apply to the Customs
Union (CU) of the Russian Federation, Belarus, and Kazakhstan
Shock & Bump IEC60255-21-2 Class 1
Seismic IEC60255-21-3 Class 2
Power magnetic Immunity IEC61000-4-8 Level 5
Pulse Magnetic Immunity IEC61000-4-9 Level 4
Damped Magnetic Immunity IEC61000-4-10 Level 4
Voltage Dip & interruption IEC61000-4-11 0,40,70,80% dips,250/300cycle
interrupts
Damped Oscillatory IEC61000-4-12 2.5KV CM, 1KV DM
Conducted RF Immunity 0-
150khz
IEC61000-4-16 Level 4
Voltage Ripple IEC61000-4-17 15% ripple
Ingress Protection IEC60529 IP40 front , IP10 Back
Environmental (Cold) IEC60068-2-1 -40C 16 hrs
Environmental (Dry heat) IEC60068-2-2 85C 16hrs
Relative Humidity Cyclic IEC60068-2-30 6day variant 2
EFT IEEE/ANSI C37.90.1 4KV, 2.5Khz
Damped Oscillatory IEEE/ANSI C37.90.1 2.5KV,1Mhz
RF Immunity IEEE/ANSIC37.90.2 35V/m (max field), (80MHz-1GHz
with 1KHz sine and 80% AM
modulation)
ESD IEEE/ANSIC37.90.3 8KV CD/ 15KV AD
UL508 e83849 NKCR
Safety UL C22.2-14 e83849 NKCR7
UL1053 e83849 NKCR
APPROVALS
Applicable Council Directive According to
Low voltage directive EN60255-5 / EN60255-27 / EN61010-1
CE compliance EMC Directive EN60255-26 / EN50263
EN61000-6-2
UL508
North America cULus UL1053
C22.2.No 14
EAC Machines and Equipment TR CU 010/2011
ISO Manufactured under a registered
quality program
ISO9001
Item Description
Country of origin Spain or Canada; see label on the unit
Date of manufacture See label on the side of the 345 unit
Declaration of Conformity and/or Certificate of
Conformity
Available upon request
TESTING AND CERTIFICATION
TEST REFERENCE STANDARD TEST LEVEL
