66 345 TRANSFORMER PROTECTION SYSTEM – QUICKSTART GUIDE
SOFTWARE SETUP CHAPTER 3: INTERFACES
Protection summary Protection Summary is a single screen which holds the summarized information of
different settings from Grouped Elements, Control Elements and Maintenance screens.
Protection Summary Screen allows the User to:
• view the output relay assignments for the elements
• modify the output relay assignments for the elements
• view the enable/disable status of Control Elements
• navigate to the respected Protection Element screen on a button click.
The Protection Summary screen is as follows:
