345 Transformer Protection System
Chapter 2: Installation
GE
Grid Solutions
Instal lation
Mechanical installation
This section describes the mechanical installation of the 345 system, including dimensions
for mounting and information on module withdrawal and insertion.
Dimensions
The dimensions of the 345 are shown below. Additional dimensions for mounting and
panel cutouts are shown in the following sections.
