20 345 TRANSFORMER PROTECTION SYSTEM – QUICKSTART GUIDE
MECHANICAL INSTALLATION CHAPTER 2: INSTALLATION
Figure 2-7: Panel cutout dimensions
5.350” 0.010”
(135.9 mm 0.25mm)
±
±
4.100” 0.010”
(104.1 mm 0.25 mm)
±
±
0.200”
(5.1 mm)
Φ
6.900” 0.010”
(175.3 mm 0.25 mm)
±
±
6.000” 0.010”
(152.4 mm 0.25 mm)
±
±
4.000” 0.010”
(101.6 mm 0.25 mm)
±
±
C
L
C
L
