5-4 SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
OPC–UA POINT LISTS CHAPTER 5: 350 OPC–UA COMMUNICATION STANDARD
Table 5-2: Digital points
Vaux_ang Auxiliary Voltage angle
IseqPos_mag Positive Sequence Current magnitude
IseqPos_ang Positive Sequence Current angle
IseqNeg_mag Negative Sequence Current magnitude
IseqNeg_ang Negative Sequence Current angle
IseqZero_mag Zero Sequence Current magnitude
IseqZero_ang Zero Sequence Current angle
VseqPos_mag Positive Sequence Voltage magnitude
VseqPos_ang Positive Sequence Voltage angle
VseqNeg_mag Negative Sequence Voltage magnitude
VseqNeg_ang Negative Sequence Voltage angle
VseqZero_mag Zero Sequence Voltage magnitude
VseqZero_ang Zero Sequence Voltage angle
Power1_WGF 32N Wattmetric Power1
Power2_WGF 32N Wattmetric Power2
Power1_32DP Directional Power1
Power2_32DP Directional Power2
Ia_2ndHarmc 2nd Harmonic Ia
Ib_2ndHarmc 2nd Harmonic Ib
Ic_2ndHarmc 2nd Harmonic Ic
Therm_Cap_PhA Thermal Capacity PhA
Therm_Cap_PhB Thermal Capacity PhB
Therm_Cap_PhC Thermal Capacity PhC
Enrgy_Mvarh_Neg Mvarh Generation
Enrgy_MWh_Neg MWh Generation
Enrgy_Mvarh_Pos Mvarh Consumption
Enrgy_MWh_Pos MWh Consumption
Data Description
Data
PIOC_1_PKP Phase IOC1 PKP
PIOC_1_phA_PKP Phase A IOC1 PKP
PIOC_1_phB_PKP Phase B IOC1 PKP
PIOC_1_phC_PKP Phase C IOC1 PKP
PIOC_1_OP Phase IOC1 OP
PIOC_1_phA_OP Phase A IOC1 OP
PIOC_1_phB_OP Phase B IOC1 OP
PIOC_1_phC_OP Phase C IOC1 OP
PIOC_1_BLK Phase IOC1 BLK
PIOC_2_PKP Phase IOC2 PKP
PIOC_2_phA_PKP Phase A IOC2 PKP
PIOC_2_phB_PKP Phase B IOC2 PKP
PIOC_2_phC_PKP Phase C IOC2 PKP
PIOC_2_OP Phase IOC2 OP
PIOC_2_phA_OP Phase A IOC2 OP
PIOC_2_phB_OP Phase B IOC2 OP
Data Description
