CHAPTER 8: MODBUS FUNCTIONS FUNCTION CODE 05H
SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 8-5
Commands are different for each 3 Series relay:
339 Commands:
345 Commands:
Virtual Input 6 0x1005 Virtual Input 22 0x1015
Virtual Input 7 0x1006 Virtual Input 23 0x1016
Virtual Input 8 0x1007 Virtual Input 24 0x1017
Virtual Input 9 0x1008 Virtual Input 25 0x1018
Virtual Input 10 0x1009 Virtual Input 26 0x1019
Virtual Input 11 0x100A Virtual Input 27 0x101A
Virtual Input 12 0x100B Virtual Input 28 0x101B
Virtual Input 13 0x100C Virtual Input 29 0x101C
Virtual Input 14 0x100D Virtual Input 30 0x101D
Virtual Input 15 0x100E Virtual Input 31 0x101E
Virtual Input 16 0x100F Virtual Input 32 0x101F
Description Coil Address (DEC)
Reset 1
Lockout Reset 2
Open 4
Close 5
Validate RMIO 12
Emergency Restart 13
Clear Last Trip Data Prompt 96
Reset MWh and Mvarh Meters 97
Clear Trip Counters 99
Clear Event Records 100
Clear Waveform Data 101
Clear Data Logger 103
Clear Learned Data 106
Trigger Waveform Capture 120
Start Data Log 121
Stop Data Log 122
Clear Security Log 126
Simulate Key Press - Nav Up Key 142
Simulate Key Press - Nav Left Key 143
Simulate Key Press - Nav Down Key 144
Simulate Key Press - Nav Right Key 145
Simulate Key Press - Up Key 146
Simulate Key Press - Down Key 147
Simulate Key Press - Enter Key 148
Simulate Key Press - Menu Key 149
Simulate Key Press - Escape Key 150
Simulate Key Press - Reset Key 151
Reload Factory Setpoints 2 161
Reload Factory Setpoints 1 162
Motor Data Logger Clear 182
Description Coil Address (HEX) Description Coil Address (HEX)
