10-2 SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
339 MODBUS MEMORY MAP CHAPTER 10: 339 MODBUS MEMORY MAP AND FORMAT CODES
30051 0x32 Comm Build Date 0 6 1 --- F22 Unknown 6
30057 0x38 Comm Build Time 0 4 1 --- F22 Unknown 4
30061 0x3C Comm Revision 0 0xFFFF 1 --- F3 230 1
30063 0x3E Comm Boot Code Revision 0 0xFFFF 1 --- F3 200 1
30064 0x3F RMIO Value 0 4 1 --- F22 4
30068 0x43 FPGA Revision 0 0xFFFF 1 --- F3 0 1
30135 0x86 Main Boot Code Date 0 6 1 --- F22 Unknown 6
30141 0x8C Main Boot Code Time 0 4 1 --- F22 Unknown 4
30145 0x90 Comms Boot Code Date 0 6 1 --- F22 Unknown 6
30151 0x96 Comms Boot Code Time 0 4 1 --- F22 Unknown 4
LAST TRIP DATA
30186 0xB9 Cause of Last Trip 0 59 1 --- FC134 0 1
REAL-TIME CLOCK
30223 0xDE Weekday 0 7 1 --- None 0 1
30224 0xDF Current Date 0x010107D9 0x0C1F0833 0 --- F18
0x010107D
9
2
30226 0xE1 Current Time 0 0X173BEA5F 0 --- F19 0 2
30228 0xE3 Daylight Savings Active 0 1 1 --- FC126 0 1
TRIP COUNTERS
30230 0xE5 Total Number of Trips 0 10000 1 --- F1 0 1
COUNTERS
30246 0xF5 Number of Emergency
Restarts
0 65535 1 --- F1 0 1
30257 0x100 Number of Motor Starts 0 65535 1 --- F1 0 1
30259 0x102 Motor Running Hours 0 65535 1 hrs F1 0 1
TIMERS
30262 0x105 Start Timer 1 0 3600 1 s F1 0 1
30263 0x106 Start Timer 2 0 3600 1 s F1 0 1
30264 0x107 Start Timer 3 0 3600 1 s F1 0 1
30265 0x108 Start Timer 4 0 3600 1 s F1 0 1
30266 0x109 Start Timer 5 0 3600 1 s F1 0 1
30270 0x10D Overload Lockout 0 65535 1 s F1 0 1
30271 0x10E Starts/Hour Block 0 3600 1 s F1 0 1
30272 0x10F Time Between Starts
Lockout Time
0 3601 1 s F1B 0 1
30273 0x110 Restart Block 0 50000 1 s F1 0 1
30278 0x115 Therman Inhibit Timer 0 65535 1 s F1 0 1
30279 0x116 Motor Lockout Time 0 65535 1 s F1 0 1
INPUTS / OUTPUTS
30285 0x11C Contact Input 32-1 (Bit Field) 0 0xFFFFFFFF 1 --- FC167 0 2
30288 0x11F Virtual Input 32-1 (Bit Field) 0 0xFFFFFFFF 1 --- FC167 0 2
30290 0x121 Virtual Output 32-1 (Bit Field) 0 0xFFFFFFFF 1 --- FC167 0 2
30296 0x127 Remote Input 32-1 (Bit Field) 0 0xFFFFFFFF 1 --- FC167 0 2
30298 0x129 Contact Output 32-1 (Bit
Field)
0 0xFFFFFFFF 1 --- FC167 0 2
30300 0x12B Remote Output 32-1 (Bit
Field)
0 0xFFFFFFFF 1 --- FC167 0 2
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
words
