CHAPTER 2: RS485 INTERFACE DNP PROTOCOL SETTINGS
SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 2-15
Some fault report data has been scaled to fit into a 16-bit value as follows:
- 13 Fault Report In - 13 Fault Report In
- 14 Fault Report In Angle - 14 Fault Report In Angle
- 15 Fault Report Va - 15 Fault Report System Frequency
- 16 Fault Report Va Angle - 16 Fault Report Ia 2
- 17 Fault Report Vb - 17 Fault Report Ia 2 Angle
- 18 Fault Report Vb Angle - 18 Fault Report Ib 2
- 19 Fault Report Vc - 19 Fault Report Ib 2 Angle
- 20 Fault Report Vc Angle - 20 Fault Report Ic 2
- 21 Fault Report Vab - 21 Fault Report Ic 2 Angle
- 22 Fault Report Vab Angle - 22 Fault Report Ig 2
- 23 Fault Report Vbc - 23 Fault Report Ig 2 Angle
- 24 Fault Report Vbc Angle - 24 Fault Report In 2
- 25 Fault Report Vca - 25 Fault Report In 2 Angle
- 26 Fault Report Vca Angle - 26 Fault Report Idiff 1 PhA
- 27 Fault Report Vn - 27 Fault Report Idiff 1 PhA Angle
- 28 Fault Report Vn Angle - 28 Fault Report I Restraint PhA
- 29 Fault Report Vaux - 29 Fault Report I Restraint PhA Angle
- 30 Fault Report Vaux Angle - 30 Fault Report Idiff 1 PhB
- 31 Fault Report System Frequency - 31 Fault Report Idiff 1 PhB Angle
- 32 Fault Report Phases - 32 Fault Report I Restraint Ph B
0 33 Analog Input Point 0 Entry - 33 Fault Report I Restraint PhB Angle
1 34 Analog Input Point 1 Entry - 34 Fault Report Idiff 1 PhC
… … … - 35 Fault Report Idiff 1 PhC Angle
… … … - 36 Fault Report I Restraint PhC
31 64 Analog Input Point 31 Entry - 37 Fault Report I Restraint PhC Angle
- 38 Fault Report Phases
0 39 Analog Input Point 0 Entry
1 40 Analog Input Point 1 Entry
………
………
31 70 Analog Input Point 31 Entry
Fault Report Mapping 350 and 339 Fault Report Mapping 345
Disabled Enabled Disabled Enabled
Fault Report Data Scale
Fault Report Ia, Ib, Ic, Ia2, Ib2, Ic2 Format_F10 * 100 / CT Primary
Fault Report Ig, Ig2 Format_F10 * 100 / Gnd CT Primary
Fault Report In , In2 Format_F10 * 100 / CT Primary
Fault Report Va, Vb, Vc, Vab, Vbc, Vca, Vn Format_F9 * 10000 /( BusVTRatio * BusVTSecondary)
Fault Report Vaux Format_F9 * 10000 /( AuxVTRatio * AuxVTSecondary)
Fault Report System Frequency Format_F3
Fault Report Phases Format_F37
