11-2 SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
345 MODBUS MEMORY MAP CHAPTER 11: 345 MODBUS MEMORY MAP AND FORMAT CODES
30051 0x32 Comm Build Date 0 6 1 --- F22 Unknown 6
30057 0x38 Comm Build Time 0 4 1 --- F22 Unknown 4
30061 0x3C Comm Revision 0 0xFFFF 1 --- F3 230 1
30063 0x3E Comm Boot Code Revision 0 0xFFFF 1 --- F3 200 1
30068 0x43 FPGA Revision 0 0xFFFF 1 --- F3 0 1
30135 0x86 Main Boot Code Date 0 6 1 --- F22 Unknown 6
30141 0x8C Main Boot Code Time 0 4 1 --- F22 Unknown 4
30145 0x90 Comms Boot Code Date 0 6 1 --- F22 Unknown 6
30151 0x96 Comms Boot Code Time 0 4 1 --- F22 Unknown 4
LAST TRIP DATA
30186 0xB9 Cause of Last Trip 0 59 1 --- FC134 0 1
REAL-TIME CLOCK
30223 0xDE Weekday 0 7 1 --- None 0 1
30224 0xDF Current Date 0x010107D9 0x0C1F0833 0 --- F18
0x010107D
9
2
30226 0xE1 Current Time 0 0X173BEA5F 0 --- F19 0 2
30228 0xE3 Daylight Savings Active 0 1 1 --- FC126 0 1
INPUTS / OUTPUTS
30285 0x11C Contact Input 32-1 (Bit Field) 0 0xFFFFFFFF 1 --- FC167 0 2
30288 0x11F Virtual Input 32-1 (Bit Field) 0 0xFFFFFFFF 1 --- FC167 0 2
30290 0x121 Virtual Output 32-1 (Bit Field) 0 0xFFFFFFFF 1 --- FC167 0 2
30296 0x127 Remote Input 32-1 (Bit Field) 0 0xFFFFFFFF 1 --- FC167 0 2
30298 0x129 Contact Output 32-1 (Bit
Field)
0 0xFFFFFFFF 1 --- FC167 0 2
30300 0x12B Remote Output 32-1 (Bit
Field)
0 0xFFFFFFFF 1 --- FC167 0 2
DEVICE STATUS
30302 0x12D Current Security Access
Level
0 3 1 --- F1 0 1
30305 0x130 Device Status 0 0xFFFF 1 --- FC129 0 1
30317 0x13C Active Setpoint Group 0 1 1 --- F1 0 1
30319 0x13E Relay1 Coil Status 0 1 1 --- FC125 0 1
30320 0x13F Relay2 Coil Status 0 1 1 --- FC125 0 1
30321 0x140 TRIP COIL BKR2 STATUS 0 1 1 --- FC125 0 1
WINDING 1 CURRENT METERING
30324 0x143 Sensitive Ground Current 0 0xFFFFFFFF 1 A F11 0 2
30326 0x145 Neutral Current 0 100000 1 A F10 0 2
30328 0x147 Phase A Current 0 1200000 1 A F10 0 2
30330 0x149 Phase B Current 0 1200000 1 A F10 0 2
30332 0x14B Phase C Current 0 1200000 1 A F10 0 2
30338 0x151 Ground Current 0 1200000 1 A F10 0 2
30343 0x156 Ia Angle 0 359 1 ° F1 0 1
30344 0x157 Ib Angle 0 359 1 ° F1 0 1
30345 0x158 Ic Angle 0 359 1 ° F1 0 1
30349 0x15C Ground Current Angle 0 359 1 ° F1 0 1
30350 0x15D Neutral Current Angle 0 359 1 ° F1 0 1
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
words
